Precautions for using high pressure mist humidifier

　　As we all know, high-pressure micro-mist humidifiers are widely used in printing, textile, tobacco, animal husbandry, agriculture, gardening and other industries. We have some understanding of the working principle of high-pressure micro-mist humidifiers. Now let's take a look at high pressure Precautions for the use of micro-mist humidifiers.

　　1. It is strictly forbidden to operate the pump without water.

　　2. The installation height of the sprinkler head is recommended to be at least 3 meters from the ground and at least 0.5 meters from the roof. water droplets

　　3. The installation height angle of the nozzle is 5∽15° tilted upward horizontally, which is a good angle for use.

　　4. The pipe connecting the nozzle should drop 300MM every 100M, and there is a fixed point every 2M; avoid the long-term use of the connecting pipe, which will cause bending, and cause the residual water to form sediment in the pipeline for a long time, blocking the nozzle.

　　5. Before starting the machine, please screw the pressure regulating valve to the no-pressure state. After starting up, slowly adjust the pressure regulating valve and observe the pressure displayed by the pressure gauge.

　　6. If the machine is used in a cold area, attention should be paid to taking anti-freezing measures; when the main engine is installed outdoors, rain-proof measures must be taken; after use, the water supply should be cut off and the remaining water in the pump should be drained to prevent the high-pressure pump from freezing.

　　7. Before the initial operation of the high-pressure pump, add lubricating oil to the crankcase and add it to the middle of the two horizontal lines on the oil level gauge. Never fill it up; the high pressure pump needs a lube change for the first 50 hours, then every 300 hours. Use No. 40 or No. 60 oil. Due to the high technical content of the high-pressure micro-mist humidification system, there are differences in calculation, selection and configuration in different fields or occasions. Please contact our technical department for selection. I believe we can provide a high-pressure micro-mist humidification system that suits your requirements!

　　8. All the pipes of the whole system cannot use ordinary steel pipes, high-pressure seamless copper pipes, high-pressure seamless stainless steel pipes or high-pressure rubber-steel composite pipes that are easy to rust, so as to avoid rusting water from clogging the nozzles.

　　9. It can be directly connected to the water pipe, but an ultrafilter must be added to prevent the solid particles in the water from clogging the nozzle
